Magnetic Access/Parking Spare Parts

The following is a list of recommended spare parts that service partners should keep in stock for maintenance and repair on site. Additional components may be necessary if other options such as boom lighting or a boom locking system is in use with the installed barrier. This is a general list of parts that can be useful in just about any situation.


Click The Part No. To View The Product Page


Item

Part No.

Recommended Quantity For
Less Than 10 Barriers

Recommended Quantity For
10 To 100 Barriers

Upper Spring Bracket Bearings LFT02 1 3
Spring Standard 2036.5008 3 5
Spring Strong 2036.5009 3 5
Side Cover With Logo, Complete SDK01 1 3
Gasket Ring Set For Flange Shaft 1033.5029 1 3
Set Of Sliding Blocks NUTS01 1 2
Complete Set Of Gate Hardware HDW KIT 1 2
Complete Lock (Lock, Cam And 2 Keys) GTS01 1 2
Keys (2 Pcs.) GTS02 6 10
Control Unit (Non-Pro Gates) MGC-A100 1 1-2
Control Unit (Pro Gates) MGC-PRO-A100 1 1-2
2-Channel Loop Detector DM02 1 1-2
Service Module SM01 1 1
Power Supply Unit 3084.5046 1 1-2
2-Pole Main Switch 3460.5098 1 1-2
Pro Motor MHP-144A-E100 1 1
Access Pro L/H Motor MHP-145A-E100 1 1
Standard Motor - No longer available MHP-144A-E101 1 1
Access-L Motor - No longer available MHP-144A-E103 1 1
