Magnetic Access Pro-H- Barrier Gate Opener With MicroDrive - 20ft Boom (Dark Grey)

Specifically designed for applications that require a boom skirt. Boom skirts help prevent pedestrian intrusion and add more visibility to your barrier opener. This white unit includes a 20 ft MicroBoom.
Part Number: Access Pro-H-RC02010
$4,512.19 each
$4,512.19 each
OR


Details

Magnetic Access Pro-H- Barrier Gate Opener With MicroDrive - 20ft Boom (Dark Grey)

Are you looking for a way to secure an access road, and have the additional need for a boom skirt? The Access Pro-H-RC02010 barrier opener is specifically designed for applications that require a boom skirt. Boom skirts help prevent pedestrian intrusion and make your road more secure. Designed and manufactured by Magnetic AutoControl, the leading name in the barrier industry.

All Access Pro-H gate openers contain the MGC PRO control unit that is EN 13849 compliant and is easy to configure with an LCD screen. Worried about heavy wind or snow? The MHTM MicroDrive drive unit has a high torque that guarantees the best operation in the most severe weather conditions. The motor, motor control and gearing are all combined in one compact drive unit. Includes a 20 ft boom.

Includes:

  • MGC Pro Controller
  • 20' MicroBoom Barrier Boom*
  • Integrated Dual Channel Loop Detector
  • Dark Grey Powder-Coated Aluminum Housing

Features:

  • 4.0 Second Open and Close Speeds
  • Built for boom skirts
  • Selectable opening and closing times
  • Maximum power consumption of 25W
  • 10 Million opening and closing cycles
  • 2 Year Warranty

Available Options for Replacement Arms:

*Please Note: Gates with booms over 15 ft must use a pendulum support or support post. Boom skirt sold separately. A pendulum support or support post is required when using a boom skirt.

MHTM Manual

Magnetic Access Pro-H Brochure
Magnetic Access Pro-H Quick Setup

Name Magnetic Access Pro-H- Barrier Gate Opener With MicroDrive - 20ft Boom (Dark Grey)
SKU Access Pro-H-RC02010
Alternate Part Number Access Pro-H-LC02010
Manufacturer Magnetic Automation Corp.
Model Access Pro-H
Boom Length 20 ft
Speed 4.0 seconds
Color Dark Grey
Dimensions (W x D x H) 12" x 14" x 44"
Input Voltage 110/115/120 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 3 Phase), 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase)
Max Power Consumption 25 W
Protection Class IP 54
Frequency 50 / 60 Hz
Temperature Range -22°F to +122°F
Weight (without boom) 97 lbs
Price $4,512.19
